N5183B技術參數說明
N5183B頻率有13G，20G，40G，是MXG X系列微波模擬信號發生器。測試頻率跟功率，滿足生產型企業需求。N5183B性價比高。N5183B是Agilent是德品牌。品牌可靠，安全性能放心。如果你需要購買租賃N5183B都可以聯系邁凱瑞儀器
N5183B技術參數說明
N5183B貨源充足。二手N5183B對于企業來收成本低。但是售后服務無憂，購買都可以享受半年到壹年不等的售后服務。N5183B校準，租賃，購買期待你的聯系。
N5183B MXG X 系列射頻模擬信號發生器---深圳市邁凱瑞儀器提供各種服務-租賃-維修-銷售-校準
N5183B是德信號發生器參數資料：
全新二手機N5183B是德信號發生器都有現貨，N5183B性能穩定，價格低。國外貨源N5183B，國內銷售，珠三角長三角，深圳，上海，杭州，武漢，西安，北京，遼寧，天津都可以配送。N5183B信號發生器，是生產研發企業的備選。
N5183B MXG X系列微波模擬信號發生器 9 kHz to 13, 20 31.8 or 40 GHz +20 dBm output power at 20 GHz -124 dBc/Hz phase
N5183B技術參數說明主要特性與技術指標
Signal characteristics
-
9 kHz to 13, 20 31.8 or 40 GHz
-
+20 dBm output power at 20 GHz
-
-124 dBc/Hz phase noise at 10 GHz and 10 kHz offset
-
-75 dBc non-harmonics at 10 GHz and >10 kHz offset
Modulation and sweep
-
AM, FM, ?M and narrow pulse
-
Pulse train generator
-
10 MHz multifunction generator and LF out
-
Digital step and list sweep modes with <600 ?s switching speed
N5183B技術參數說明Automation and communication interfaces
-
1000BaseT LAN, LXI, USB 2.0 and GPIB
-
SCPI, IVI-COM, MATLAB drivers
-
Backward compatible with all ESG, MXG, PSG and 8648x signal generators
-
Keysight USB power sensor compatible with embedded display and SCPI control
N5183B技術參數說明描述
The pure and precise MXG
The MXG is the pure and precise alternative to the analog PSG, with advantages in size and speed. It delivers the performance you need--spectral purity, output power, switching speed and more--to perform module- and system-level testing.
Generate the signals you need with outstanding hardware performance
-
Test radar receiver sensitivity with best-in-class phase noise and spurious performance
-
Shrink your test stand with two rack-unit height
-
Maximize throughput with fast switching speed
-
Compensate for system loss, stimulate remote DUTs, and drive high-power amplifiers while retaining signal integrity
-
Simulate multi-channel composite analog modulation with integrated multifunction generation
-
Create variable RADAR PRI and pulse width with integrated pulse train generator
Maximize resources with low cost of ownership
-
Increase uptime with high mean time between failures (MTBF)
-
Minimize downtime and expenses with self-maintenance strategy and low-cost repairs
-
Standard 3-year calibration cycle and warranty
|
